Galvanized Drop Forged Eye x Eye Swivels

SKU: 51801061
Size: 1/4"
Price:
$2.88
Stock:
117 In Stock

Expected Next Available Date:

In Stock Orders Ships Same Day!!!

You can add more than the in-stock qty to your cart, and we will ship your complete order once all the stock arrives. In Stock Orders the ship same day if placed before 2PM CT. All items in your cart must be listed as In Stock. Place separate orders on in-stock and back ordered items if you want items to ship the same day. Applies to UPS shipping methods only, LTL Freight may go out the same day if carrier pick-up schedule permits.

Galvanized Drop Forged Eye x Eye Swivels

Register to receive a notification when this item comes back in stock.

Notify me when available

Quick Specs (Click to see full Specs)

Material: Hot Dip Galvanized Steel

Ultimate Tensile Strength (UTS):

Working Load Limit (WLL):

Minimum Breaking Load (MBL):

Size:

Length:

Weight:

Standard Reel Size (Flange Diameter x Height):

Shipping Note:

Imported Carbon Steel Forged Quenched and Tempered Hot Dip Galvanized ASME B30.26 RR-C-271

Return Policy: 30-Day Returns, see our return policy for more info.

Instructional Videos

Description

Galvanized Drop Forged Eye x Eye Swivels

Dimensions are in inches unless otherwise noted.

SizeWorking Load Limit (lbs)ABCDEFApproximate Weight Each (lbs)
1/48500.250.690.750.380.942.880.2
5/1612500.31250.7510.51.133.630.4
3/822500.3750.941.250.631.384.250.7
1/236000.51.381.50.811.945.631.4
5/852000.6251.631.7512.316.632.5
3/472000.751.8121.192.567.253.8
