Tyler Tool

Tyler Lever Load Hoists

SKU: 91681010
Size: 0.75 ton X 10 Foot
Sale price$169.99
50 In Stock

In Stock Orders Ships Same Day!!!

You can add more than the in-stock qty to your cart, and we will ship your complete order once all the stock arrives. In Stock Orders the ship same day if placed before 2PM CT. All items in your cart must be listed as In Stock. Place separate orders on in-stock and back ordered items if you want items to ship the same day. Applies to UPS shipping methods only, LTL Freight may go out the same day if carrier pick-up schedule permits.

Tyler Lever Load Hoists

Register to receive a notification when this item comes back in stock.

Notify me when available When will it arrive?
Return Policy: Must be unused in original un-damaged packaging, see our return policy for more info.
Material: Aluminum Housing Zinc Plated Alloy Chain

Ultimate Tensile Strength (UTS):

Working Load Limit (WLL):

Minimum Breaking Load (MBL):




Standard Reel Size (Flange Diameter x Height):

Shipping Note:



Lever Load Hoists

Product Manual and Certifications

Dimensions are in inches unless otherwise noted.

ModelRated Capacity
t (lbs)
Lift ft (m)Force Required to Lift Rated Capacity (lbs)No. of Chain FallsLoad Chain Diameter (mm)HABCDLWeight (lbs)
LH-025-030.25t (551 lbs)3 ft (1 m)N/A13.27.873.582.323.181.255.713.30
LH-050-050.5t (1102 lbs)5 ft (1.5 m)N/A14.09.843.972.483.621.336.305.51
LH-075-100.75t (1653 lbs)10 ft (3 m)5116.311.925.902.165.031.251014.55
LH-075-200.75t (1653 lbs)20 ft (6.1 m)5116.311.925.902.165.031.251014.55
LH-150-101.5t (3306 lbs)10 ft (3 m)6617.114.376.492.515.861.4114.4024.25
LH-150-201.5t (3306 lbs)20 ft (6.1 m)6617.114.376.492.515.861.4114.4024.25
LH-300-103t (6613 lbs)10 ft (3 m)9319.019.097.673.347.161.8114.4037.48
LH-300-203t (6613 lbs)20 ft (6.1 m)9319.019.097.673.347.161.8114.4037.48
