Dimensions are in inches unless otherwise noted.
L | L1 | B | H1 | B1 | L2 | D5 | D6 | Screw |
---|---|---|---|---|---|---|---|---|
3.94 | 1.18 | 0.55 | 0.59 | 0.59 | 2.17 | 0.17 | 0.31 | M4 |
4.92 | 1.38 | 0.63 | 0.63 | 0.69 | 2.52 | 0.17 | 0.31 | M4 |
5.91 | 1.77 | 0.75 | 0.75 | 0.83 | 2.85 | 0.21 | 0.39 | M5 |
7.87 | 2.17 | 0.87 | 0.87 | 0.94 | 3.54 | 0.25 | 0.45 | M6 |
9.84 | 2.76 | 0.98 | 0.98 | 1.06 | 4.33 | 0.33 | 0.59 | M8 |
