Dimensions are in inches unless otherwise noted.
Thread Diameter (D1) x Take Up (L) | Length Pin to Pin (L1): | Inside Jaw Width (A): | Pin Diameter (D): | Outside Jaw Width (B): | Inside Jaw Length (H): | WLL (lbs) | Weight (lbs) |
---|---|---|---|---|---|---|---|
1/4" x 4" | 7.15 | 0.45 | 0.24 | 0.9 | 0.62 | 460 | 0.36 |
5/16" x 4-1/2" | 8.61 | 0.49 | 0.24 | 1 | 0.87 | 620 | 0.53 |
3/8" x 6" | 10.45 | 0.53 | 0.31 | 1.08 | 0.87 | 1060 | 0.81 |
1/2" x 6" | 11.88 | 0.67 | 0.39 | 1.36 | 1.06 | 1660 | 1.62 |
