HAAS Stainless 7x19 Type 316 Stainless Steel Cable

SKU: 22505020
Size: 1/8" X 200'
Price:
$82.98
Stock:
7 In Stock

Expected Next Available Date:

In Stock Orders Ships Same Day!!!

You can add more than the in-stock qty to your cart, and we will ship your complete order once all the stock arrives. In Stock Orders the ship same day if placed before 2PM CT. All items in your cart must be listed as In Stock. Place separate orders on in-stock and back ordered items if you want items to ship the same day. Applies to UPS shipping methods only, LTL Freight may go out the same day if carrier pick-up schedule permits.

HAAS Stainless 7x19 Type 316 Stainless Steel Cable

Register to receive a notification when this item comes back in stock.

Notify me when available

Quick Specs (Click to see full Specs)

Material: Type 316 Stainless Steel Wires

Ultimate Tensile Strength (UTS):

Working Load Limit (WLL):

Minimum Breaking Load (MBL):

Size:

Length:

Weight:

Standard Reel Size (Flange Diameter x Height):

Shipping Note:

Imported Type 316 Stainless Steel RR-W-410

Return Policy: Cable cannot be returned, see our return policy for more info.

Instructional Videos

View More Blogs

Description

HAAS Stainless 7x19 Type 316 Stainless Steel Cable Reel

Product Resources

Wire Rope & Cable Warnings and Instructions
Stainless Steel Guide
Galling in Stainless Steel Guide
RoHS Statement

Cable Diameter Breaking Strength Working Load Limit (5:1) Design Factor
1/8" 1,670 lbs 334 lbs
3/16" 3,565 lbs 713 lbs
1/4" 4,900 lbs 1,175 lbs
5/16" 8,825 lbs 1,765 lbs
3/8" 11,760 lbs 2,352 lbs

Reviews

Trustpilot Reviews Logo

Customer Questions & Answers

Ask a Question

  • Do you have stainless fasteners and devices to keep the 1/8 inch cable tight

    Yes, we have plenty of Rigging Fittings that will work very well with this 7x19 cable to create cable slings with eyelets at each end.  We also carry cable railing systems which has fittings you would crimp onto the cable and then use them to tension our 1x19 cable for your deck/staircase/or fence.
